MIXING CONTAINER CR.MIX

The CR.MIX mixing container is the ideal solution for fast and efficient mixing of non-abrasive, free-flowing plastic granules or regrind. The special geometry of the mixing screw ensures the best mixing results in the shortest possible time.

Up to two suction pipes (Ø 40, Ø 50, Ø 60.3) allow easy material removal. The transparent cover provides a clear view of the mixing process.

Thanks to the mobile design (feet with castors and CEE connector plug), the CR.MIX mixing container can be used flexibly in different areas of plastics processing.

Characteristics

Container and mixing screw each made of stainless steel
Conical mixing screw without outer tube for easy cleaning
Round container with steep cone for optimum material flow
Short mixing time
Transparent cover for visual control of the mixing process
Suction at the lowest point of the cone (2 connections for suction pipes)

Complete emptying at the bottom of the outlet
Automatic switch-off at the end of the mixing process
Adjustable mixing time
High-quality components (motor, bearings) for a long working life
Mobile construction on castors and with CEE connection plug
Electro-mechanical safety devices to protect the operator

300 l - 500 l

Mixing container 300 l / 500 l

Made of stainless steel
Four steel feet (RAL9005)
Two fixed castors and two lockable swivel castors
2 suction connections

Make a request!

Accessories

Suction tube for CR.MIX

Suction air regulation through sliding sleeve
Suction air regulation can be snapped in, with scale
Twist coupling system with hose connection

	Ø
CR.MIX.Z.SAUGROHR.040	40
CR.MIX.Z.SAUGROHR.050	50
CR.MIX.Z.SAUGROHR.060	60.3
