SILO FILLING DIVERTER VALVE

Our silo filling diverter valves distribute your high-quality bulk materials by means of pneumatic pressure conveying from one feed point into several silos. They are seamlessly integrated into the pipe system. We also have suitable pipe systems.

Rotary switch

Rotary switch (pressure conveying)
  • Housing and cover made of cast aluminium
  • Product-carrying parts made of aluminium,
    hard anodized
  • Flanged pipe sections made of stainless steel
  • Silicone seal
  • Pneumatically driven
  • 5/2-way magnetic valve, 24 V DC
  • End position control with two proximity switches
  • Bulk material temperature max. 80 °C
  • Ambient temperature -20 to + 40°C
  • Working pressure range max. 1.0 bar
Make a request!

Dimensions

  Ø L F D H1 H2
W.02.076 76.1 706 82 435 115 346
W.02.108 108 746 92 465 125 356
W.02.129 129 756 97 475 142 374
45° bends with flanges
  • Made of stainless steel
  • With screw set and seal
  • Radius 800 mm

Dimensions

  Ø L1/L2 Flange
W.02.FL.080.RB.076.45 76.1 x 2.0 200/200 DN80/DN150
W.02.FL.100.RB.089.45 88.9 x 2.0 200/200 DN100/DN150
W.02.FL.100.RB.108.45 108 x 2.0 200/200 DN100/DN150
W.02.FL.125.RB.129.45 129 x 2.0 200/200 DN125/DN150
90° bends with flanges
  • Made of stainless steel
  • With screw set and seal
  • Radius 800 mm

Dimensions

  Ø L1/L2 Flange
W.02.FL.080.RB.076.90 76.1 x 2.0 200/200 DN150
W.02.FL.100.RB.089.90 88.9 x 2.0 200/200 DN150
W.02.FL.100.RB.108.90 108 x 2.0 200/200 DN150
W.02.FL.125.RB.129.90 129 x 2.0 200/200 DN150
